Last updated: September 16, 2026.
Yes, many Toyota RAV4 models can tow a U-Haul trailer, but the correct trailer depends on your exact model year, grade, drivetrain, towing rating, payload, hitch setup, trailer brake equipment, and loaded trailer weight. For 2026, Toyota lists a 1,750-lb towing capacity for the lower-rated configurations and up to 3,500 lbs for specified AWD grades. For 2025, gas RAV4 models are rated up to 1,500 lbs, Hybrid models up to 1,750 lbs, and the RAV4 Plug-in Hybrid up to 2,500 lbs.
U-Haul currently lists its 4′ x 8′ cargo trailer at 850 lbs empty, the 5′ x 8′ at 900 lbs, and the 6′ x 12′ at 1,920 lbs. Always compare the trailer’s actual loaded weight with the rating for your exact RAV4 and complete U-Haul’s vehicle-specific compatibility check before reserving.
Quick Answer
- 2026 RAV4: Toyota lists 1,750 lbs for LE AWD and up to 3,500 lbs on specified AWD grades. Confirm the exact rating for your configuration before towing.
- 2025 RAV4: Gas models are rated up to 1,500 lbs, Hybrid models up to 1,750 lbs, and the Plug-in Hybrid up to 2,500 lbs.
- U-Haul 4′ x 8′: 850 lbs empty. It gives the most vehicle-side weight headroom of the current enclosed U-Haul cargo trailers.
- U-Haul 5′ x 8′: 900 lbs empty. It is only 50 lbs heavier than the 4′ x 8′, but your loaded total must still stay within every applicable limit.
- U-Haul 6′ x 12′: 1,920 lbs empty. It already exceeds a 1,500- or 1,750-lb RAV4 tow rating, but some higher-rated RAV4 configurations can potentially tow it when its loaded weight remains within the vehicle’s limit.
- Speed: U-Haul’s maximum recommended towing speed is 55 MPH.
- Do not use towing capacity alone: Check payload, GVWR, GAWR, tongue-load limits, hitch ratings, trailer brake requirements, and the unbraked trailer rating in your exact Toyota owner’s manual.
| RAV4 Rating | 4′ x 8′ at 850 lbs | 5′ x 8′ at 900 lbs | 6′ x 12′ at 1,920 lbs |
|---|---|---|---|
| 1,500 lbs | 650 lbs theoretical vehicle-side headroom | 600 lbs theoretical vehicle-side headroom | Too heavy empty |
| 1,750 lbs | 900 lbs theoretical vehicle-side headroom | 850 lbs theoretical vehicle-side headroom | Too heavy empty |
| 2,500 lbs | Up to 1,650 lbs before other limits | 1,600 lbs theoretical vehicle-side headroom | 580 lbs theoretical vehicle-side headroom |
| 3,500 lbs | Trailer max-load limit controls before vehicle TWR | Trailer max-load limit controls before vehicle TWR | 1,580 lbs theoretical vehicle-side headroom |
Important: The figures above are simple towing-rating minus empty-trailer-weight calculations, not loading authorizations. Your usable cargo allowance can be lower because of the trailer’s own maximum load, U-Haul’s rental limits, your RAV4’s payload/GVWR/GAWR, tongue load, hitch components, brake requirements, and other vehicle-specific restrictions.
What Is the Toyota RAV4 Towing Capacity?
The Toyota RAV4 does not have one universal towing capacity. The limit changes by model year, drivetrain, grade, and equipment.
2026 RAV4 Towing Capacity
Toyota redesigned the RAV4 for 2026 and moved the U.S. lineup to Hybrid and Plug-in Hybrid powertrains. Toyota lists a 1,750-lb towing capacity for LE AWD and up to 3,500 lbs for several higher-capability AWD configurations, including XLE Premium AWD, Woodland, and SE AWD. Check the specification for your exact grade because the rating is not determined by the RAV4 name alone.
See Toyota’s current 2026 RAV4 specifications for the latest U.S.-market grade information.
2025 RAV4 Towing Capacity
- 2025 RAV4 gas: Up to 1,500 lbs
- 2025 RAV4 Hybrid: Up to 1,750 lbs
- 2025 RAV4 Plug-in Hybrid: Up to 2,500 lbs
The 2025 Plug-in Hybrid was previously known as RAV4 Prime. Toyota changed the model name to RAV4 Plug-in Hybrid for model year 2025.
For other years, do not copy the 2025 or 2026 numbers. Use your exact model-year owner’s manual or Toyota’s owner’s manual lookup.
Do Not Use a Generic Tongue-Weight Number
Tongue load is the downward load the trailer places on the hitch. It also uses part of the RAV4’s available payload. Follow the tongue-load requirements in the owner’s manual for your exact model year and configuration rather than using one fixed pound figure for every RAV4.
U-Haul instructs renters to load approximately 60% of the cargo weight in the front half of the trailer and 40% in the rear. That front-biased loading helps establish proper hitch load and reduces the risk of trailer sway. Do not exceed the RAV4’s tongue-load, payload, axle, hitch, or trailer limits.
Which U-Haul Trailers Can a Toyota RAV4 Tow?
The safest way to choose a trailer is to start with your RAV4’s exact towing rating, subtract the trailer’s empty weight, and then apply every other limit in the system. U-Haul also checks the tow vehicle during the reservation process and can assign a lower allowed cargo weight for the specific combination.
[Amazon Products Picked for You]
Impressive Weight Capacity: With a maximum distributed weight capacity of 500 pounds, this hitch cargo carrier confidently supports your cargo needs, ensuring secure transportation
VERSATILE. The 5/8-inch diameter of this hitch pin is compatible with any ball mount or other trailer hitch accessories with a 2-inch or 2-1/2-inch shank and 5/8-inch pin hole to fit virtually any class 3, 4 or 5 hitch
How Do the Current U-Haul Cargo Trailers Compare?
- 4′ x 8′ Cargo Trailer: 850 lbs empty, with a 1,650-lb maximum cargo load and 2,500-lb maximum gross trailer weight. It provides the most weight headroom of U-Haul’s current enclosed cargo trailers.
- 5′ x 8′ Cargo Trailer: 900 lbs empty, with a 1,800-lb maximum cargo load and 2,700-lb maximum gross trailer weight. It gives more interior room while adding only 50 lbs of empty weight compared with the 4′ x 8′.
- 6′ x 12′ Cargo Trailer: 1,920 lbs empty, with a 2,480-lb maximum cargo load and 4,400-lb maximum gross trailer weight. It also has an automatic hydraulic surge-brake system.
Current U-Haul Cargo Trailer Weight Limits
These are the current published specifications from U-Haul’s cargo-trailer guide:
| Trailer Type | Empty Weight | Max Load | Max Gross Weight |
|---|---|---|---|
| 4′ x 8′ Cargo Trailer | 850 lbs | 1,650 lbs | 2,500 lbs |
| 5′ x 8′ Cargo Trailer | 900 lbs | 1,800 lbs | 2,700 lbs |
| 6′ x 12′ Cargo Trailer | 1,920 lbs | 2,480 lbs | 4,400 lbs |
Important: A trailer’s maximum load is not the amount your RAV4 is automatically allowed to carry. The allowable loaded trailer weight is controlled by the lowest applicable limit in the complete combination.
Which Trailer Makes Sense for Each RAV4 Tow Rating?
- 1,500-lb-rated RAV4: The 4′ x 8′ and 5′ x 8′ are the only current enclosed U-Haul cargo trailers light enough when empty. Even then, the remaining theoretical tow-rating headroom is only 650 lbs or 600 lbs before other limits.
- 1,750-lb-rated RAV4: The 4′ x 8′ leaves 900 lbs of theoretical tow-rating headroom and the 5′ x 8′ leaves 850 lbs. The 6′ x 12′ is already too heavy empty.
- 2,500-lb-rated RAV4: The 4′ x 8′ and 5′ x 8′ offer much more vehicle-side headroom. A 6′ x 12′ is below the vehicle’s rating when empty but leaves only 580 lbs before reaching 2,500 lbs.
- 3,500-lb-rated RAV4: All three current enclosed cargo trailers can potentially fall within the vehicle’s towing rating. A 6′ x 12′ still must stay at or below 3,500 lbs loaded, leaving 1,580 lbs of vehicle-side cargo headroom before other limits.
Before choosing a hitch or trailer, you can also review our Toyota RAV4 towing capacity guide and RAV4 trailer hitch guide.
Can the RAV4 Tow a 6′ x 12′ U-Haul Trailer?
It depends on the RAV4’s exact tow rating. The U-Haul 6′ x 12′ cargo trailer weighs 1,920 lbs empty.
- A 1,500-lb-rated RAV4 cannot tow it because the empty trailer already exceeds the vehicle rating.
- A 1,750-lb-rated RAV4 cannot tow it for the same reason.
- A 2,500-lb-rated RAV4 has 580 lbs of theoretical vehicle-side weight headroom after accounting for the empty trailer.
- A 3,500-lb-rated RAV4 has 1,580 lbs of theoretical vehicle-side weight headroom, so the trailer can potentially fit within TWR if the loaded trailer remains at or below 3,500 lbs and every other vehicle, hitch, payload, brake, axle, and U-Haul requirement is also satisfied.
U-Haul lists an automatic hydraulic surge brake on the 6′ x 12′. It also requires the appropriate hitch system, lighting connection, mirrors, hitch ball setup, and tow-vehicle compatibility. Complete U-Haul’s reservation validation rather than assuming that Toyota’s maximum tow rating alone approves the rental.
[Amazon Products Picked for You]
【Safety Notice】- Tighten the ball before installation. Before each use, pls check for any looseness between the ball and its mount
Factory Fit: Our Class 3 trailer hitches are custom design according to manufacturer specifications to ensure a perfect fit
【MULTI-TOW KIT】NeaLia Premium 7 and 4 Pin Trailer Connector integrates 7 blade round trailer socket and 4 way flat adapter, perfect for people who go between the two plugs often, such as pickup, trucks, SUV, camper and RVs drivers; NOTE: the dual sockets cannot be used simultaneously
What Safety Limits Matter Besides Towing Capacity?
Towing capacity is only one number in the calculation. You also need to stay within the RAV4’s payload, GVWR, GAWR, tongue-load and hitch-component limits.
Check the unbraked trailer rating too. U-Haul’s current 6′ x 12′ cargo trailer specifically lists hydraulic surge brakes. The current 4′ x 8′ and 5′ x 8′ product pages list a 4-way lighting connection but do not list the same surge-brake feature. Verify the brake equipment on the actual rental trailer and compare it with the unbraked trailer rating in your exact Toyota owner’s manual before loading.
U-Haul also states that the loaded trailer must not exceed its maximum gross weight or any lower allowed weight shown on the rental contract. If in doubt about your loaded weight, use a certified or commercial scale.
U-Haul’s trailer instructions call for about 60% of cargo weight in the front half of the trailer. Loading too much weight behind the axle increases the risk of dangerous sway.
How Do You Prepare a RAV4 for a U-Haul Trailer?
- Confirm the exact RAV4 rating: Check the model year, grade, drivetrain, owner’s manual, certification labels, payload and towing specifications.
- Use the lowest-rated component: The RAV4, receiver, ball mount, hitch ball, pin and trailer all have limits. A high-capacity aftermarket hitch does not increase the RAV4’s factory towing rating.
- Confirm trailer wiring: The trailer lights must work before you tow. U-Haul’s current cargo trailers use a 4-way flat lighting connection.
- Match the hitch ball and height: U-Haul lists a 1 7/8-inch or 2-inch hitch ball with at least a 2,000-lb rating for its 4′ x 8′ and 5′ x 8′ cargo trailers and specifies a maximum allowable hitch-ball height of 25 inches.
- Inspect tires and connections: Check RAV4 and trailer tire condition and pressure, safety chains, coupler, hitch pin, wiring and lights.
- Load front-heavy, not rear-heavy: Follow U-Haul’s approximately 60/40 front-to-rear cargo distribution and secure every item so it cannot shift.
[Amazon Products Picked for You]
EASY GRIP. Plugging in your trailer wiring and trailer lights is easy with the ergonomic design of this trailer plug. It features tabs on the top and bottom for a better grip when plugging into your vehicle or unplugging
STANDARD FIT. This trailer wiring mounting bracket is designed to securely mount virtually any industry-standard 4-way flat connector
4 Way Flat Plug End: - This Trailer side 4 pin trailer wiring male plug fits wide variety of trailers with industry-standard 4-way flat sockets; Ideal for marine boat trailer, horse trailer, motorcycle trailer, ATV trailer, and other cargo utility
How Fast Should You Drive While Towing a U-Haul?
U-Haul’s maximum recommended towing speed is 55 MPH. Do not exceed that recommendation even if the highway’s posted passenger-vehicle speed limit is higher. Drive slower when weather, traffic, curves, grades, trailer behavior, or road conditions require it.
Leave more following distance than you would without a trailer. Brake earlier, make gradual lane changes, and slow before curves. On long downhill grades, reduce speed before the descent and use an appropriate lower transmission range or engine-braking strategy recommended by Toyota instead of continuously riding the brakes.
If the trailer begins to sway, follow U-Haul’s instructions: release the accelerator, hold the steering wheel straight, and avoid abrupt steering or braking. Once the combination is stable, stop safely and check the load distribution before continuing.
What Should You Inspect Before a Towing Trip?
- RAV4: Check tire pressure and condition, fluid levels, warning lights, brakes, cooling-system condition and scheduled maintenance.
- Hitch system: Check the receiver, ball mount, hitch ball, pin/clip, coupler and safety-chain attachment points.
- Trailer: Inspect tires, lights, wiring, coupler, safety chains, door/latch and visible damage.
- Brake equipment: Confirm whether the actual trailer has brakes and whether your RAV4’s braked or unbraked trailer rating applies.
- Loaded weight: Know the trailer’s empty weight and the weight of your belongings. Use a scale when the total is close to any limit.
Recheck the hitch connection, lights and load after driving a short distance. If the trailer feels unstable, stop and correct the problem rather than trying to compensate by driving faster or making steering corrections.
What Can Real-World RAV4 Towing Reports Tell You?
Owner reports can help you understand practical issues such as reduced fuel economy, slower acceleration, longer stopping distances, crosswind sensitivity, hitch clearance, and the difficulty of reversing a trailer. They are not a substitute for Toyota’s or U-Haul’s published limits.
Why Owner MPG and Weight Claims Vary
Fuel economy while towing can change substantially with trailer size, aerodynamics, cargo weight, speed, elevation, wind, temperature and the specific RAV4 powertrain. A single owner’s MPG result should therefore be treated as an anecdote, not a prediction for another vehicle or trip.
Which Owner Tips Are Consistent With Official Guidance?
The most useful recurring owner advice is also reflected in official towing guidance: know the loaded weight, keep the cargo secured and front-biased, allow more room for braking, practice backing and turning before a long trip, and stop if the trailer begins to behave unpredictably.
For a first towing trip, practicing low-speed turns and reversing in an open area can make the vehicle-trailer combination easier to manage before entering traffic.
Related Guides
Frequently Asked Questions
What Is the Maximum Tongue Weight for a Toyota RAV4?
There is no single tongue-weight number that should be applied to every RAV4. The correct limit depends on the exact model year, configuration and towing equipment. Check your Toyota owner’s manual and vehicle-specific hitch documentation, and make sure tongue load plus passengers and cargo do not push the RAV4 beyond its payload, GVWR or axle ratings.
Can I Tow a U-Haul Trailer With a RAV4 Hybrid?
Yes, many RAV4 Hybrid configurations can tow a U-Haul cargo trailer. The exact towing rating varies by model year and configuration. A 2025 RAV4 Hybrid is rated up to 1,750 lbs, while specified 2026 AWD Hybrid grades are rated up to 3,500 lbs. Compare your exact rating with the trailer’s loaded weight and complete U-Haul’s compatibility check.
Does Towing Affect the RAV4’s Fuel Efficiency?
Yes. A trailer adds weight and aerodynamic drag, so fuel economy normally falls while towing. The size of the reduction depends on trailer shape, loaded weight, speed, weather, grades and the RAV4 powertrain.
Are There Any Aftermarket Towing Accessories for the RAV4?
Yes. Vehicle-specific receiver hitches, wiring harnesses, ball mounts, hitch balls, pins and other towing hardware are available for many RAV4 model years. Confirm exact fitment and use the lowest-rated component in the complete towing system. An aftermarket hitch does not raise Toyota’s towing capacity.
How Does Towing Impact the RAV4’s Warranty?
Follow Toyota’s published towing, payload, maintenance and equipment requirements for your exact vehicle. Warranty coverage depends on the cause of a failure and the applicable warranty terms, so do not assume either that towing automatically voids the warranty or that damage caused by overloading will be covered. Review the warranty guide for your model year if a specific coverage question arises.
Can a Toyota RAV4 Tow a 6′ x 12′ U-Haul?
A 1,500- or 1,750-lb-rated RAV4 cannot tow the 6′ x 12′ cargo trailer because U-Haul lists it at 1,920 lbs empty. A 2,500- or 3,500-lb-rated RAV4 can potentially stay within its towing rating, but the actual loaded weight, payload, hitch, brake, axle and U-Haul compatibility requirements still control.
Final Thoughts
A Toyota RAV4 can tow a U-Haul trailer when the specific vehicle and trailer combination stays within every applicable limit. The easiest current enclosed U-Haul trailers to match with a lower-rated RAV4 are the 850-lb 4′ x 8′ and 900-lb 5′ x 8′. The 1,920-lb 6′ x 12′ requires a RAV4 rated above that empty weight and enough remaining capacity for the cargo.
Before reserving, identify your RAV4’s exact model year and configuration, check Toyota’s towing and unbraked-trailer limits, total the trailer plus cargo weight, confirm the hitch and lighting setup, and run the vehicle through U-Haul’s compatibility system. While towing, follow U-Haul’s 55-MPH maximum recommended speed and 60/40 cargo-loading guidance.
